PTD-10
Time Distributor with DIN Rail
Product Overview

PTD-10 Time Distributor can provide more output ports for time synchronization system. It support two input signals as redundancy time source and verify input signal to dispatch precise time signal via output port to more IEDs and implement time synchronization. The cable delay compensation can be set to maintain time output accuracy.

Key Features

Maximum 2 inputs as redundancy time source for Best Time Source selection。
Maximum 16 output ports can connect more IEDs
Support BNC, Terminal, Optical interface
Support IRIG-B signal with B000, B001, B002, B003, B004, B005, B006 and B007
Cable delay compensation can be set by manual
Alarm contact indicate device status
LCD time display

Specifications
Functions
Redundancy Time Source PTD-10 Time Distributor can solve time redundancy input and install it before IED to verify input signal and select the best one as time source
Physical Media Converter PTD-10 Time Distributor can provide TTL and Fiber Optical interface converter.
Port Capacity Expansion PTD-10 Time Distributor can provide a flexible solution to expand more ports to connect more IEDs.
Long Distance Transmission PTD-10 Time Distributor can be installed the middle of time server and IED to provide long distance signal transmission.
Time Input Support maximum 2 input ports
BNC Interface, optional optical fiber MM interface
Time Output Support maximum 16 output ports
Terminal Interface, optional optical fiber MM interface
Product Specifications
Input Interface TTL: 5VDC, 50Ω, BNC connector
Optical (Optional): Multi-mode, 850nm or 1310nm, ST connector
Output Interface TTL: Terminal connector
Optical (Optional): Multi-mode, 850nm or 1310nm, ST connector
Display Operation Interface LCD: 2*24 Characters, show status and make configuration
Key: 4 keys to indicate Up, Down, Enter, Esc
LED Power status: PSW
Alarm status: ALARM
Time input #1: S1
Time input #2: S2
Running status: RUN
Alarm Interface Relay: NC and NO relay alarm contact, 3-pin 5.08mm-spacing plug-in terminal block, 250 VAC Max, 3 A Max
Maintenance Interface Console: RS232, RJ45, one port
Power Requirements Power input:
100-240VAC,50/60Hz;110-220VDC(85-264VAC/85-300VDC)
24VDC(21.6-26.4VDC)
48VDC(43.2-52.8VDC)

Power terminal: 3-pin 7.62 mm-spacing plug-in terminal block
Power Consumption: <18W
Physical Characteristics Housing: Metal
Cooling: Natural cooling, fanless
Dimensions(WxHxD): 482.6mm×44.2mm×229mm (19×1.74×9.02 in.)
Weight: <3Kg (6.61pound)
Environmental limits Operating temperature: -20°C to +70°C (-4°F to 158°F)
Storage temperature: -40°C to +85°C (-40°F to 185°F)
Ambient Relative Humidity: 5% to 95% (non-condensing)
Quality assurance Warranty: 5 years
Approvals
Product Performance
Time Accuracy ±50ns (Input to Output)
IRIG-B Demodulated Signal B000,B001,B002,B003,B004,B005,B006,B007
Mechanical Drawing

Ordering Information

MODEL
FT208S Fiber/TTL, 2 Inputs, 8 Outputs, Management
FT216S Fiber/TTL, 2 Inputs, 16 Outputs, Management
POWER
3 48VDC(43.2-52.8VDC) Single
5 24VDC(21.6-26.4VDC) Single
7 100-240VAC,50/60Hz;110-220VDC(85-264VAC/85-300VDC) Single
INPUT
1 TTL BNC
2 Optical ST, MM 850nm
3 Optical ST, MM 1310nm (Customized Interface)
OUTPUT
1 TTL Terminal
2 Optical ST, MM 850nm
3 Optical ST, MM 1310nm (Customized Interface)



  Order Information Description
PO (DEMO) PTD-10-FT216S-7-11 100-240VAC,50/60Hz;110-220VDC(85-264VAC/85-300VDC) Single
2 TTL BNC input ports
16 TTL Terminal output ports
Management
